Head Up Display HUD

1194/5000
COMPATIBILITY:

- Universal, for Cars
- OBD II and EU OBD socket


FOR AN OPTIMAL ASSEMBLY, WE RECOMMEND:

- CLEANING: Thoroughly clean the part of the windshield where your digital speedometer will be projected.

- CONTROL: Connect the Plug and Play OBD socket to check operation; if there are no problems, proceed with the assembly.

- POSITIONING: Position the Anti-Slip Mat and the HUD on the Dashboard Checking if you like the Projection Point.

- REMOVE THE REFLECTIONS: Once the Projection Point on the Windshield has been identified, Adhering the Remove-Reflection Film will make the Image sharper.


For an Excellent Result we always recommend Installation by an expert, as it will also Hide the wire.


SETTING:

- the button moves in three directions: left, forward, right
- Hold the Forward direction button down for 5 sec. (Enter the menu)
- Light Press Direction Forward Button (Scroll the Menu)
- Left and Right Button Direction (Changing Parameters)
- Press and hold the Forward direction button for 5 sec. (Save and Exit the Menu)

(Check the Instruction Booklet for the settable parameters)
