For Mercedes

COMPATIBILITY

- For Mercedes G Class (W463) 1989-2018


FOR OPTIMUM ASSEMBLY, WE ALWAYS RECOMMEND INSTALLATION BY AN EXPERT

- The Headlight has the same connections as the original, therefore it will not be necessary to make changes to the wiring, the PLUG AND PLAY rule (connection only) will apply.


ASSEMBLY:

- Remove the old headlight by unscrewing the two screws on the sides
- Remove the original bulbs and the black plastic in which they were housed
- Mount the two black extension brackets supplied (the matte side must be placed on the metal plate, the new headlights will be mounted on the smooth side)
- Connect the cables: Green (Side Lights), Red (Braking Lights), Yellow (Turning Lights), and the Black cable will be connected to the Negative Pole
- After connecting the cables, mount the light on the brackets using the central holes located on the external edges of the brackets

STANDARD CABLE COLORS MERCEDES G-CLASS PRE-FACELIFT:
- Brown, Negative Pole
- Grey/Red, Position Lights
- Black, Braking Lights
- Green/Black, Turning Lights

STANDARD CABLE COLORS MERCEDES G CLASS FACELIFT:
- Brown, Negative Pole
- Grey/Black, Position Lights
- Red/Black, Braking Lights
- White/Black, Turning Lights

PS. Using the switch connected to the rear of the headlight you can decide whether to have the dynamic Turn light or not.



We do not assume responsibility for: incorrect purchases - violations of regulations or laws of each state - damage that could be caused to you, to third parties, to the Vehicle or to the item itself, as we describe every single specification in detail.

We also remind you that these are Aftermarket Items, designed for Full compatibility and operation on the designated vehicle, but they remain products that may not be permitted for use on public roads.

We trust in your common sense.
